DNS Optical patchcord OM2, 50/125, 2xLC-LC

Reference: 200230

Condition: New product

DNS Patch cord is made of two parallel sections of multimode fiber optic cable with a lengths of 1, 2, 3, 5, 10 and 15 meter, terminated on both sides with two LC connectors.

More details

More info
Data sheet
Download
Warranty

DNS Patch cord is made of two parallel sections of multimode fiber optic cable with a lengths of 1, 2, 3, 5, 10 and 15 meter, terminated on both sides with two LC connectors. LC connectors feature simple matching (push-pull coupling with a snap) and rectangular cross-section allowing dense packing of the connectors on the panel.

The optical fiber used in the patch cord is OM2. It provides full compatibility with existing fiber-optic networks based on multimode fibers. The average fiber attenuation is 3.5 dB/km at 850 nm and 1.5 dB/km at 1310 nm. The optical fiber is reinforced by aramid fibers (Kevlar) and covered with PVC sheath.

FEATURES

Kevlar reinforced
Comes in standard with 2mm outer jacket.
All connectors are equipped with zirconia ferruls and conform to TIA/EIA568.3, Bellcore GR-02
Testprotocol comes with each item.
Bending radius: 30 mm

Ordering information

Code	Description	Length
200230	DNS OM2 2xLC-LC, 50/125	1 m
200231	DNS OM2 2xLC-LC, 50/125	2 m
200232	DNS OM2 2xLC-LC, 50/125	3 m
200233	DNS OM2 2xLC-LC, 50/125	5 m
200234	DNS OM2 2xLC-LC, 50/125	10 m
200235	DNS OM2 2xLC-LC, 50/125	15 m

Subject to change without notice

Connectors	LC (A, B) - LC (A, B)
Insertion loss	≤0.3dB
Return loss	≤25dB
Repeatability	≤0.1dB
Durability	≤0.2dB, typically change 1000 matings
Interchangeability	≤0.1dB
Tensile strength	more than 10 kg
Patchcord length	1, 2, 3, 5, 10 and 15 meter
Fiber type	50/125, OM2
Standards	EN6079-1-23; EN60874-1:2012; Telecordia GR-326-CORE; EN50173

Warranty (EN)

DNS Warranty Program

Download (437.14k)

DNS Warranty System

The DNS System Warranty provides a 25-year product applications warranty. The guarantee cover system and application performance according to EN50173-1:2002, ANSI/TIA/EIA-568-B.2:2002 and ISO/IEC 11801-2 at the time of proper signed application form. The warranty may be applied by the certified DNS Partner.
